Micro-organisms

The two dozen that decide who lives where there is no doctor: what each does, how it spreads, what kills it and which step stops it.

Home: Hygiene and disease, Level 1 · Foothold, level 1 of 3 in its track. Serves 11 steps across 5 subjects.

Where there is no doctor, most deaths from infection come from four routes: water and food carrying faeces, wounds, the air, and insect bites. Each route has a small number of organisms that do most of the killing, and each one has a known weak point: a temperature, a time, a chemical dose, a filter size or a habit. This guide is the basic set, about two dozen organisms, each with the number that stops it. It is not a catalogue. The formal record of every named micro-organism is kept by the nomenclature registries listed under Further, and the diseases are covered in full by WHO and CDC.

Medical content on this site has not yet been reviewed by a qualified practitioner (CIV-054). Check anything you act on against the WHO and CDC pages linked below.

What kills them

Learn this table first: it is what the rest of the guide keeps pointing back to. The right column matters as much as the middle one, because each method has organisms it misses.

MethodDose that worksKillsDoes not kill
Rolling boil1 minute; 3 minutes above 2,000 mBacteria, viruses, Giardia, CryptosporidiumBacterial spores (tetanus, botulism); toxins already made in food by Staphylococcus or moulds
Chlorine (household bleach)2 drops of 5% bleach per litre, 30 minutes before drinking. WHO: at least 0.5 mg/L free chlorine left after 30 minutesMost bacteria and virusesCryptosporidium: chlorine tablets do not kill it. Giardia needs longer contact. Spores
Filter1 µm absolute pore size or finer, or a ripened slow sand filterGiardia and Cryptosporidium (4–6 µm), most bacteriaViruses, which are far smaller: disinfect after filtering
Sunlight (SODIS)Clear PET bottle, 3 litres or less, 6 hours in full sunMost bacteria and virusesMuddy water: sunlight cannot get through
Cooking70 °C or hotter all the way throughE. coli O157, Salmonella and other bacteria in foodSpores; Staphylococcus toxin; aflatoxin
Pressure canning116–121 °CBotulism sporesNothing in the jar survives: this is sterilisation
AcidpH below 4.6Stops botulism growingDoes not sterilise: it only prevents growth
DryingGrain below 13% moistureStops the moulds that make aflatoxinToxin already made stays
Soap and waterAt least 20 seconds, then rinseRemoves most germs from hands, including norovirusGerms on hands you then wipe on a dirty cloth
Heat does not undo a toxin already madeStaphylococcus toxin and aflatoxin survive cooking, so food left warm for hours, or grain that went mouldy, stays poisonous however well it is reheated. Botulinum toxin is the exception: it is destroyed above 85 °C for 5 minutes, but its spores survive hours of boiling. Throw out any jar that is bulging, leaking or spurting when opened.

Spread by water and food

All of these leave the body in faeces and enter by the mouth. They are stopped by the same three things: safe water, waste kept apart from water and hands washed with soap. Treat diarrhoea with oral rehydration whatever the cause: the fluid loss kills before the germ does.

Vibrio cholerae, stained, under the light microscope: short curved rods shaped like commas. One litre of cholera stool can hold billions of them. Vibrio cholerae gram stain CDC · 1979 · CDC · Public domain · Commons ↗
Cryptosporidium parvum oocysts, fluorescent stain, with a 10 µm scale bar: each is 4–6 µm across. Chlorine at drinking-water doses does not kill them; a 1 µm filter holds them back and boiling kills them. Cryptosporidium parvum 01 · Unknown · Public domain · Commons ↗
OrganismWhat it doesSick afterWhat kills itStopped by
Vibrio cholerae (bacterium)Cholera: sudden, massive watery diarrhoea. Untreated, it can kill within hours12 hours to 5 daysBoiling, chlorineSafe water; oral rehydration saves most patients
Salmonella Typhi (bacterium)Typhoid: fever rising over days, stomach pain. Some people carry it for years without symptoms6–30 daysBoiling, chlorine, cookingSafe water; carriers kept out of food handling
Shigella (bacterium)Dysentery: bloody diarrhoea. A very small dose infects1–2 daysBoiling, chlorine, soapHandwashing with soap
E. coli O157 (bacterium)Bloody diarrhoea; up to 10% develop kidney failure (haemolytic uraemic syndrome), mostly children3–8 days, usually 3–4Cooking to 70 °CCook minced meat through; do not drink raw milk
Hepatitis A (virus)Liver infection: yellow skin and eyes, weeks of weakness14–28 daysBoiling, chlorineSafe water, handwashing; a vaccine exists
Norovirus (virus)Sudden vomiting and diarrhoea; spreads through a household in days12–48 hoursBoiling; soap and waterHandwashing; sick people kept out of cooking
Giardia (protozoan)Weeks of greasy, foul diarrhoea and wind1–2 weeksBoiling, 1 µm filter; resists chlorineSafe water from lakes and streams
Cryptosporidium (protozoan)Watery diarrhoea; dangerous in infants and the malnourished2–10 days, usually 7Boiling, 1 µm filter; not chlorine tabletsBoil or filter; keep livestock out of water sources

Wounds and skin

The skin keeps these out until it is broken. What saves the wound is cleaning it at once and keeping everything that touches it clean: see wound care and germ theory and antisepsis. In 1847 Ignaz Semmelweis cut deaths from childbed fever in his Vienna maternity ward by making doctors wash their hands in chlorinated lime; the killer was Streptococcus pyogenes.

Clostridium tetani: rods each carrying a round spore at one end, like a drumstick. The spores live in soil and dung, survive boiling, and cause tetanus when they reach a deep wound. Clostridium tetani · 1995 · Content Providers(s): CDC · Public domain · Commons ↗
Staphylococcus aureus, Gram stain: purple spheres about 1 µm across in grape-like clusters, the pattern that separates it from Streptococcus, which forms chains. Staphylococcus aureus Gram stain · 2021-05-19 14:42:22 · Dr Graham Beards · CC BY-SA 4.0 · Commons ↗
OrganismWhat it doesSick afterWhat kills itStopped by
Clostridium tetani (bacterium)Tetanus: jaw lock, then spasms of the whole body. Spores live in soil, dung, ash and on rusty tools3–21 days, most within 14Spores survive boiling; steam sterilisation at 121 °C kills themClean deep wounds at once and leave contaminated ones open; the tetanus vaccine
Staphylococcus aureus (bacterium)Boils, infected wounds, blood poisoning. In food left warm, a toxin that causes vomitingFood poisoning: within hoursCooking kills the bacterium but not its toxinClean dressings; keep cooked food hot or cold, never warm for hours
Streptococcus pyogenes (bacterium)Sore throat, spreading skin infection, childbed fever after birth2–5 daysSoap, chlorine, penicillinHandwashing before touching a wound or a birth; antibiotics

Poisons made in food

These do not need to infect you. They grow in stored food and leave a poison behind, so the rule is about how food is kept, not only how it is cooked. The numbers are the ones in preserving the harvest and the preservation guide.

OrganismWhat it doesSick afterHow it growsStopped by
Clostridium botulinum (bacterium)Botulism: double vision, drooping eyelids, then paralysis that stops breathing12–36 hours (4 hours to 8 days)Without air, in food above pH 4.6: home-canned vegetables, meat, fish, garlic in oilAcid below pH 4.6, or pressure canning at 116–121 °C; boiling for 5 minutes destroys the toxin
Aspergillus flavus (mould)Aflatoxin: liver damage and liver cancer; large doses kill in weeksChronic, or days after a large doseWarm, damp stored maize, groundnuts and other grainDry grain below 13% moisture; throw out mouldy grain; cooking does not help
Claviceps purpurea (fungus)Ergotism: burning limbs, gangrene, convulsionsDays to weeks of eating itReplaces grains of rye and other cereals with dark purple-black bodiesClean seed; pick out and burn the dark bodies before milling

Diseases to recognise

These cannot be stopped with a boil or a filter. They are recognised by their signs and slowed by the habits in the last column, and cured only at the antibiotics and vaccines tier. A health authority that counts cases is what shows an outbreak starting.

Mycobacterium tuberculosis in sputum, Ziehl–Neelsen stain: thin red rods that keep the red dye through acid alcohol, on a blue background. This is how a clinic confirms TB with a microscope. Mycobacterium tuberculosis Ziehl-Neelsen stain 02 · created 1979 · CDC/Dr. George P. Kubica · Public domain · Commons ↗
Thin blood smear at 1,000×: the purple crescent is a Plasmodium falciparum gametocyte, the stage a mosquito takes up when it bites; the grey discs are red blood cells. Plasmodium falciparum malaria, 1000x · 2015-01-04 · Department of Pathology, Calicut Medical College · CC BY-SA 4.0 · Commons ↗
OrganismWhat it doesSick afterHow it spreadsSlowed by
Mycobacterium tuberculosis (bacterium)Tuberculosis: cough lasting weeks, sometimes with blood; fever, night sweats, weight loss. About a quarter of the world is infectedMonths to yearsThrough the air when a sick person coughsVentilation and daylight; the sick kept apart; treatment is 4–6 months of daily medicine
Plasmodium (protozoan)Malaria: fever, chills and sweats in cycles; P. falciparum can kill in days10–15 days after the biteBites of female Anopheles mosquitoes, at nightNets over sleepers, screens, draining standing water; artemisinin combination therapy; quinine, from cinchona bark, before it
Measles (virus)Fever, then a rash spreading from the face. Kills through pneumonia and blindness, above all in the malnourished7–14 daysThrough the air; one case infects about 18 people who are not immuneTwo doses of vaccine; for sick children under 5, two doses of vitamin A
Rabies (virus)Fear of water, agitation, paralysis. Once symptoms show, 100% fatalUsually 2–3 months (1 week to 1 year)Bites and scratches of infected animals; dogs cause 99% of human casesWash any bite with soap and water for at least 15 minutes, at once; vaccine after the bite

Microbes to put to work

The same knowledge runs the other way. Most food preservation, all brewing, the first antibiotics and the fertility of legume fields are microbes doing the work. See fermentation and distilling.

Baker's yeast, Saccharomyces cerevisiae, through a school microscope's 40× objective: oval cells about 5 µm long, unstained. A bead microscope shows the same cells. Baking yeast cells under 40x microscope objective · 2023-01-02 22:03:33 · ~delta · CC BY-SA 4.0 · Commons ↗
Nodules on legume roots, each a colony of Rhizobium bacteria fixing nitrogen from the air. Cut one open: pink or red inside means it is fixing; white or green means it is not. Root Nodules with leghaemoglobin 'pink' visible · 2014-04-07 04:12:14 · Rosser1954 · CC BY-SA 4.0 · Commons ↗
OrganismWhat it makesWhat it needsUsed in
Saccharomyces cerevisiae (yeast)Alcohol and carbon dioxide from sugar: glucose → 2 ethanol + 2 CO₂Sugar, warmth, no air for alcoholBread, beer, wine; distilling for stronger spirit and disinfectant
Lactic acid bacteria (Lactobacillus, Leuconostoc)Lactic acid, which drops the pH below 4 and preserves the food2–2.5% salt by weight, no airSauerkraut, pickles, yoghurt, silage: preserving
Acetobacter (bacterium)Vinegar: acetic acid from alcoholAirPickling needs vinegar of at least 5% acidity
Penicillium (mould)Penicillin, found by Alexander Fleming in 1928Grown in deep tanks for yieldThe first antibiotic
Rhizobium (bacterium)Nitrogen from the air, fixed in legume root nodulesLegume roots: clover, beans, peas, vetchA legume ley adds 50–200 kg of nitrogen per hectare: holding fertility
Methanogens (archaea)Biogas, roughly 50–70% methane, from manure and sewageNo air, and warmthFuel from waste: see the sanitation guide

Build the gear

Where to go next

This page covers what you are most likely to meet. It is not a field guide, and on identification that difference can kill you. These are the works that go further — chosen because they can be held offline.

Still to come

Illustrations carry a technique further than prose, but some things only move well. Recorded here rather than left implicit.

  • Micrographs of Giardia cysts and Entamoeba as they appear in a stool sample under a simple microscope
  • A Gram-stain procedure using dyes and reagents a tier-3 settlement can make
