Fire, and keeping it

Make fire from nothing, then never make it from nothing again.

Tier 0 · Any survivor, day one Energy t0-fire Ready to attempt
A bow drill in use: bearing block in the left hand, wrist locked to the shin, foot on the board, spindle outside the bow. Feu-archet · No machine-readable author provided. 120 assumed (based on copyright claims). · CC BY 2.5 · Commons ↗

Everything for this step

Field guide
Fire → 8 sections Poisons → 2 sections Energy sources → 14 sections
Builds
None yet.
Reference sheets
16 sheets in Energy sources
Sciences it rests on
Chemistry · Physics
Track
Fire and fuel, level 1 of 4 · next: Charcoal

Why this matters

Fire is the root of the entire technology tree. It is drinking water, warmth, cooked calories, hardened wood, pottery, lime, metal, and glass. Every temperature-gated step above this one is a descendant of this fire.

The shape of it

  1. Prepare before you spark. Tinder (fibrous, dry, teased into a bird's nest), kindling graded from matchstick to thumb, and fuel wood — all within reach, all dry — before any attempt. Most failures are unprepared fuel, not failed ignition.
  2. Take dead standing wood, never wood off the ground. Snap-test it: it should crack, not bend.
  3. Bow drill: a softwood hearth board (willow, cedar, cottonwood), a harder spindle, a bearing block, and a bow with a lace. Cut a notch that opens onto a leaf or bark tray so the hot dust collects. Work up gradually; when smoke is heavy and dust has built up, stop, transfer the coal to the tinder bundle, and blow steadily.
  4. Anything faster, use it. A lens, a curved mirror, ferrocerium, a battery shorted through steel wool, flint and steel. Friction is the method of last resort, not of first choice.
  5. Bank the fire nightly. Rake coals together, cover with ash and a green log. In the morning uncover, feed fine tinder, and blow. A banked fire is the difference between a two-minute morning and a two-hour one.
  6. Designate a fire keeper and a second. This is a real job with a real shift.
  7. Site the fire with a stone reflector at the back and a windbreak, and never inside an unventilated shelter — carbon monoxide from a smouldering fire kills people in their sleep with no warning.
The bow drill, set up and in use Fig 1
Earth / subsoilTimberGravel / aggregateFire / hot zoneVoid / air
Two details decide whether this works, and both are invisible in a photograph. The spindle ends are different: blunt at the bottom to make friction, sharpened to a cone at the top to avoid it. And the cord wraps once around the spindle, which then sits outside the bow — not inside it.
The notch — the part that is got wrong most often Fig 2
TimberGravel / aggregateFire / hot zoneVoid / air
Burn the socket first, then cut the notch into it. Cutting the notch first gives the spindle nothing to sit in and it walks straight out. The notch takes roughly an eighth of the circle and must reach the centre: stop short and the dust piles where no air gets to it, cut too wide and the spindle drops through.

Doing it, step by step

The summary above says what has to happen. This says how, with the numbers that decide whether it works.

1 · Grade and stack all the fuel before you make a single spark

This is where most attempts are lost, and it happens before anyone touches a drill. You need three grades, all dry, all within arm's reach of where you will kneel:

  • Tinder — hair-fine and fibrous. Two double handfuls. Teased birch bark, inner bark from dead cedar or lime, dry grass heads, seed down, cramp ball fungus, fine wood shavings. It must be dry enough to crumble to dust between your palms.
  • Kindling — three sub-grades, a good armful of each: matchstick, pencil, and thumb. Graded, not mixed.
  • Fuel — wrist to forearm thickness, enough stacked to burn for two hours.

A coal lives for perhaps a minute. Anything you have to go and look for during that minute is a failed fire.

✓ Check: You can crush a pinch of the tinder between your palms and it makes dust rather than stringing out. If it strings, it is damp.

2 · Take dead standing wood, and snap-test everything

Wood lying on the ground has been drinking for as long as it has been there, whatever the surface feels like. Take dead branches still attached to a tree, or standing dead trees.

The test is the sound. A dry stick breaks with a sharp crack and a clean fracture. A damp one bends, tears, or breaks with a dull thud and a fibrous face. Test every grade, not just the big pieces.

If everything is soaked, split the fuel wood open — the inside of a split log is dry even after days of rain — and make feather sticks from the dry heartwood.

Feather sticks. Split dry heartwood out of a wet log and shave it into curls that stay attached — kindling made from wood that looked unusable. フェザースティック · 2015-10-03 14:22:37 · 相馬 拓也 · CC BY-SA 4.0 · Commons ↗
✓ Check: Every grade cracks rather than bends. The split face of a fuel log is pale and dry, not darkened.

3 · Use the fastest ignition source you have — friction is the last resort

Friction fire is a skill worth owning and a terrible first choice. Anything on this list beats it, and every one of them should be tried before the bow comes out:

  • A lens. A magnifier, a spectacle lens, a clear bottle base filled with water, or a lens of clear ice. Focus to the smallest, brightest point you can and hold it steady on dark tinder. Seconds, in decent sun.
  • Ferrocerium rod. Scrape hard with a square-edged steel at about 45°. Sparks land at some 3,000 °C and will take almost any dry tinder.
  • Flint and steel. A high-carbon steel struck down the sharp edge of a flint, throwing sparks onto char cloth or amadou. This will not light raw tinder — it needs a charred catcher.
  • Battery and steel wool. Fine grade steel wool across the terminals of any battery from a torch upward.
  • A parabolic reflector. The bottom of a polished can, a torch reflector, a make-up mirror.

Keep at least two working methods at all times, and keep them in different places.

A flint-and-steel kit: flint, steel striker, char cloth and amadou. The steel will not light raw tinder — it needs a charred catcher. DirkvdM tinder box · 24 November 2006 (according to · No machine-readable author provided. DirkvdM assumed (based on copyright claims) · CC BY-SA 3.0 · Commons ↗
Hoof fungus on birch, the source of amadou. Sliced, beaten and dried it holds a spark for hours and will carry fire for a day. Fomes fomentarius 2010 G2 · 2010-06-05 · George Chernilevsky · Public domain · Commons ↗
Forged fire steels. The striking face is high-carbon steel; sparks come off it, not off the flint. Firesteels assorted · 2009-06-12 · Gaius Cornelius · CC BY-SA 3.0 · Commons ↗
✓ Check: You can name your primary and your backup ignition method, and you have used both at least once.

4 · Cut the bow drill set to these dimensions

The numbers matter more than the wood species. Aim for:

  • Hearth board — softwood, 20 mm thick, flat on the underside so it does not rock. Willow, cottonwood, cedar, lime, ivy, clematis. Too thick and you never burn through; too thin and you burn through before enough dust collects.
  • Spindle — 22 mm diameter, 250 mm long, straight, of the same wood or slightly harder. The two ends are cut differently and this is not optional: blunt and rounded at the bottom to maximise friction, sharpened to a cone at the top to minimise it.
  • Bearing block — hardwood, bone, antler or stone with a socket in it. Grease the top socket — green leaf, animal fat, earwax. Never grease the bottom end.
  • Bow — 60–90 cm, about arm's length, stiff, with a slight natural curve.
  • Cord — strong enough not to part under load. It wraps once round the spindle, and the spindle then sits outside the bow.

The cord should be tight enough that you have to twist the spindle in with some force, and no tighter.

✓ Check: With the spindle loaded, you can draw the bow one full stroke and the spindle turns through several revolutions without the cord slipping or riding up.

5 · Burn in the socket, then cut the notch

In that order. Set the socket about one spindle-width in from the edge of the board, so the notch you cut later can reach its centre.

Bow gently and slowly until a round, blackened socket has formed to a depth of two or three millimetres, and stop. You are not trying to make fire yet, only a seat for the spindle.

Now cut the notch: a V taking roughly an eighth of the socket circle, cut cleanly from the edge of the board right through to the centre of the burnt socket, and straight down through the board. Cut it slightly wider at the bottom than the top if you can.

Slide a piece of bark or a dry leaf under the notch to catch what falls.

Cutting the notch before burning in the socket is the commonest failure of all. With no seat, the spindle walks out of position under load, and it will do it faster the harder you work.
✓ Check: The notch reaches the centre of the socket, and you can see daylight through it from underneath.

6 · Bow it — position first, then speed

Kneel on your right knee with your left foot on the board, close beside the socket. Load the spindle, bearing block in your left hand, and lock your left wrist hard against your left shin. That bone-to-bone contact is what holds the spindle vertical; arm strength will not.

Start with long, slow, full-length strokes using the whole bow. Do not saw at it with short jabs. As smoke builds, increase speed and downward pressure together — more speed alone polishes the socket, more pressure alone stalls it.

You are watching the notch, not the smoke. Smoke comes early and means little. What you want is the notch filling with dark brown-black powder. When it is full and smoke is pouring off it, give ten more hard, fast strokes and stop.

A bow drill in use: bearing block in the left hand, wrist locked to the shin, foot on the board, spindle outside the bow. Feu-archet · No machine-readable author provided. 120 assumed (based on copyright claims). · CC BY 2.5 · Commons ↗
✓ Check: The dust in the notch is dark chocolate-brown to black and powdery. Light brown, gritty dust means not enough pressure; a glazed shiny socket means too much speed and not enough bite.

7 · Leave the coal alone before you touch it

Stop bowing and do nothing for twenty to thirty seconds. The pile of hot dust needs to consolidate into a single coal, and it will keep smoking on its own — that is it working, not it dying. This waiting is the hardest instruction on the page to follow, and rushing it is the second commonest failure.

Then: tap the board once, firmly, to shake the coal free of the notch, and lift the board straight up and away, leaving the coal sitting on the bark tray. Do not tip, slide or scrape it.

The coal is small — match-head to pea. Fan it gently with your hand if it looks like fading. Carry it on the tray to the tinder bundle rather than carrying the bundle to it.

✓ Check: The coal keeps smoking by itself on the tray for thirty seconds with no help from you.

8 · Blow the bundle to flame

Shape the tinder into a bird's nest: coarse fibre outside, the finest material you have in the middle. Drop the coal into the middle and fold the nest loosely around it — loosely. A squeezed bundle smothers.

Hold it up, away from your face and to one side, and blow long, steady, increasing breaths into it. Not puffs. The smoke will thicken until it is pouring, then it will go quiet for a moment, and then it will take with a bang and a lot of flame. Expect that; it is why the bundle is held away from your face and clear of your sleeve.

Place the burning bundle into the base of the laid fire. Do not build the fire around it while it burns.

Birch bark taking flame. Its oils burn even when the bark is wet, which makes it the most forgiving tinder in any temperate forest. Näver som tändmaterial 2015 · 2015-07-08 16:57:16 · Deryni · CC BY-SA 4.0 · Commons ↗
✓ Check: The bundle goes to open flame within about thirty seconds of steady blowing.

9 · Lay the fire so it never needs relighting

Build the lay before the coal exists, and leave a doorway in it for the burning bundle.

Start with a platform of dry sticks laid on the ground — cold, wet ground pulls heat out of a young fire faster than anything else. On that, stand matchstick kindling in a small cone, then pencil around it, then thumb. Leave gaps: a fire that cannot breathe makes smoke.

Only add wrist-thick fuel once the thumb grade is burning strongly and there is a bed of coals forming. Adding it early is how a good coal is wasted.

Set a stone or log reflector at the back to throw heat forward, and a windbreak on the weather side.

Never burn a fire in an unventilated space. Carbon monoxide from a smouldering fire is odourless, painless, and kills people in their sleep with no warning at all. A tent, a snow hole, a closed shelter and a sealed room are all lethal. This kills more people than the fire itself ever does.
✓ Check: The fire is still burning without attention twenty minutes after the tinder bundle went in.

10 · Bank it overnight, and never start from nothing twice

This is the whole point of the step. Making fire is hard; keeping it is nearly free, and every hour spent making it again is an hour not spent on anything else.

At night: rake the coals into a compact heap, cover them with fine ash to a depth of about 50 mm, and lay a green or damp log across. The ash starves the coals of air enough to slow them almost to nothing without putting them out.

In the morning: scrape the ash off, expose the glowing centre, feed the finest tinder onto it and blow. Two minutes rather than two hours.

To carry fire, use a slow match — a punk-wood or fungus ember in a ventilated horn, tin or bark tube — or a bundle of smouldering tinder fungus. A carried ember will keep for hours and will restart a camp at the far end of a day's walk.

A bed of coals under ash — what a banked fire looks like when it is uncovered in the morning. 2008-05-26 Early morning fire · 2008-05-26 · Ildar Sagdejev (Specious) · CC BY-SA 3.0 · Commons ↗
✓ Check: You have banked the fire and revived it from its own coals on three consecutive mornings without using an ignition source.

11 · Appoint a fire keeper, in words, out loud

A fire with no owner goes out. Name a keeper and a second, say it aloud so everyone hears it, and hand over explicitly at the end of a shift — the handover is the part that fails, not the watching.

The keeper's standing job is fuel: keeping the graded stacks topped up and under cover, and watching the fuel radius. A camp that burns everything within easy walking distance in its first winter has to move in its second. Start thinking about charcoal and about coppicing long before the wood runs short.

✓ Check: Ask anyone in the group who is keeping the fire tonight, and they can name the person.

What it looks like

Feather sticks. Split dry heartwood out of a wet log and shave it into curls that stay attached — kindling made from wood that looked unusable. フェザースティック · 2015-10-03 14:22:37 · 相馬 拓也 · CC BY-SA 4.0 · Commons ↗
A flint-and-steel kit: flint, steel striker, char cloth and amadou. The steel will not light raw tinder — it needs a charred catcher. DirkvdM tinder box · 24 November 2006 (according to · No machine-readable author provided. DirkvdM assumed (based on copyright claims) · CC BY-SA 3.0 · Commons ↗
Hoof fungus on birch, the source of amadou. Sliced, beaten and dried it holds a spark for hours and will carry fire for a day. Fomes fomentarius 2010 G2 · 2010-06-05 · George Chernilevsky · Public domain · Commons ↗
A bed of coals under ash — what a banked fire looks like when it is uncovered in the morning. 2008-05-26 Early morning fire · 2008-05-26 · Ildar Sagdejev (Specious) · CC BY-SA 3.0 · Commons ↗

How this fails

Letting it go out with no established second method of ignition. Always hold a spare route.
Burning green or ground-damp wood, producing smoke and no heat.
Enclosed fire without ventilation. Odourless, painless, fatal.
Burning through the local fuel supply within walking distance in the first winter — plan the fuel radius early, and start charcoal thinking before you need it.

How you know it worked

VerificationThe fire has not gone out for a week, and at least two people can restart it from raw materials in under an hour.
